JUMBO SERIES
PRODUCT |
JUMBO PLUS |
JUMBO 35 |
JUMBO 42 |
VOLTAGE |
230V-1-50Hz | 230V-1-50Hz | 230V-1-50Hz |
POWER |
0,35 - 0,45 KW | 0,55 KW | 0,55 KW |
CAPACITY |
8 m 3/h | 16 m 3/h | 16 m 3/h |
CYCLE TIME |
15 - 35 sec | 15-30 sec | 20-40 sec |
DIMENSION (mm) |
330 x 450 x 295 | 450 x 525 x 385 | 490 x 525 x 430 |
SEALING BAR LENGTH (mm) |
280 | 350 | 420 |
SEALING DEPTH (mm) |
310 | 370 | 370 |
CHAMBER DEPTH (mm) |
345 | 430 | 415 |
HEIGHT (mm) |
85 | 150 | 180 |
BOXER series
PRODUCT |
BOXER 35 |
BOXER 42 |
BOXER 42 XL |
BOXER 42 XL BI-ACTIVE |
VOLTAGE |
230V-1-50Hz | 230V-1-50Hz | 230V-1-50Hz | 230V-1-50Hz |
| POWER | 0,55 KW | 0,75 - 1,0 KW | 0,75 - 1,0 KW | 0,75 - 1,0 KW |
| CAPACITY | 16 m 3/h | 21 m 3/h | 21 m 3/h | 21 m 3/h |
| CYCLE TIME | 15-30 sec | 15-35 sec | 20-40 sec | 15-35 sec |
| DIMENSION (mm) | 450 x 525 x 385 | 490 x 525 x 430 | 490 x 610 x 445 | 490 x 610 x 420 |
| SEALING BAR LENGTH (mm) | 350 | 420 | 420 | 420 |
| SEALING DEPTH (mm) | 370 | 370 | 460 | 460 |
| CHAMBER DEPTH (mm) | 430 | 415 | 505 | 505 |
| HEIGHT (mm) | 150 | 180 | 180 | 120 |
FALCON SERIES
PRODUCT |
FALCON 52 |
FALCON 80 |
FALCON 2-60 |
FALCON 2-70 |
VOLTAGE |
400V-3-50Hz | 400V-3-50Hz | 400V-3-50Hz | 400V-3-50Hz |
POWER |
2,4 - 3,5 KW | 3,0 - 5,0 KW | 2,4 - 3,5 KW | 3,5 - 4,5 KW |
CAPACITY |
063 m3/h | 100 m3/h | 063 m3/h | 100 m3/h |
CYCLE TIME |
15-40 sec | 15-40 sec | 15-40 sec | 15-40 sec |
DIMENSION (mm) |
700 x 690 x 1070 | 900 x 820 x 1070 | 1060 x 880 x 1070 | 1260 x 1010 x 1070 |
SEALING BAR LENGTH (mm) |
500 | 800 | 450 | 550 |
SEALING DEPTH (mm) |
520 | 500 | 580 | 700 |
HEIGHT (mm) |
230 | 235 | 235 | 235 |
MARLIN SERIES
PRODUCT |
MARLIN 42 |
MARLIN 42 XL |
MARLIN 46 |
MARLIN 52 |
MARLIN 90 |
VOLTAGE |
230V-1-50Hz | 230V-1-50Hz | 400V-3-50Hz | 400V-3-50Hz | 400V-3-50Hz |
POWER |
0,75 - 1,0 kW | 0,75 - 1,0 kW | 2,3 - 3,2 kW | 2,4 - 3,5 kW | 2,4 - 3,1 kW |
CAPACITY |
21 m 3/h | 21 m 3/h | 40 m 3/h | 63 m 3/h | 63 m 3/h |
CYCLE TIME |
15-35 sec | 20-40 sec | 15-40 sec | 15-40 sec | 15-40 sec |
DIMENSION (mm) |
490x525x985 | 490x610x985 | 780x660x970 | 700x690x1030 | 1065x480x960 |
SEALING BAR LENGTH (mm) |
420 | 420 | 580 | 500 | 890 |
SEALING DEPTH (mm) |
370 | 460 | 460 | 520 | 320 |
HEIGHT (mm) |
180 | 180 | 110 | 200 | 100 |
POLAR SERIES
PRODUCT |
POLAR 52 |
POLAR 80 |
POLAR 2-40 |
POLAR 2-50 |
VOLTAGE |
400V-3-50Hz | 400V-3-50Hz | 400V-3-50Hz | 400V-3-50Hz |
POWER |
2,4 - 3,5 KW | 3,0 - 5,0 KW | 3,3 - 4,5 KW | 3,5 - 5,3 KW |
CAPACITY |
63 m 3/h | 100 m 3/h | 63 m 3/h | 100 m 3/h |
CYCLE TIME |
15-40 sec | 15-40 sec | 15-40 sec | 15-40 sec |
DIMENSION (mm) |
700 x 730 x 1100 | 920 x 790 x 1125 | 1545 x 790 x 1090 | 1545 x 900 x 1175 |
SEALING BAR LENGTH (mm) |
500 | 800 | 620 | 620 |
SEALING DEPTH (mm) |
520 | 500 | 400 | 500 |
HEIGHT (mm) |
200 | 200 | 240 | 240 |
dz SERIES
DZ-400 DZ-500
MODEL |
DZ-400 |
DZ-500 |
| CHAMBER DIMENSIONS (LxWxH) | 440 x 440 x 150 mm | 525 x 525 x 100 mm |
| SEALING BAR LENGTH | 400 mm | 500 x 10 mm |
| VACUUM PUMP | 25 m³/h | 20 m³/h |
| PACKAGING TIME | 10 - 50 sec | 10 - 30 sec |
| CABINET | Stainless Steel | Stainless Steel |
| VOLTAGE / POWER | 220V / 1Ph / 50Hz / 1.5kW | 220V / 1Ph / 50Hz / 0.8kW |
| WEIGHT | 92kg | |
| MACHINE DIMENSIONS (LxWxH) | 480 x 630 x 950 mm | 660 x 580 x 960 mm |
VS400-B2
VS400-B2 (European style automatic stainless steel vacuum packager)
MODEL |
VS400-B2 |
| CHAMBER DIMENSIONS (LxWxH) | 440 x 420 x 75 mm |
| SEALING BAR LENGTH | 400 x 10 mm |
| VACUUM PUMP CAPACITY | 20 m³/h, Cycle Time: 10-25 sec |
| VOLTAGE | 1 Phase 220V/50Hz |
| POWER CONSUMPTION | 0.8KW |
| MACHINE DIMENSIONS (LxWxH) | 550 x 485 x 600 mm |
DZ300TN/A
DZ300TN/A Table Top Stainless Steel Vacuum Chamber
Stainless Steel Housing / High Transparent Lid
MODEL |
DZ300TN/A |
| SEALING BAR (L x W) | Single, 260 x 8 mm |
| VAUUM PUMP CAPACITY | 10 m³/h |
| CYCLE TIME | 10 - 20 sec |
| VOLTAGE | 1 Phase 220V/50Hz |
| POWER | 0.4 kW |
| CHAMBER DIMENSIONS | 385 x 280 x 50 mm |
| MACHINE DIMENSIONS (LxWxH) | 490 x 450 x 320 mm |
